Artec Space Spider Handheld 3D Scanner
Industrial 3D scanner of metrological accuracy
A new and enhanced precision instrument for CAD users and engineers, Artec Space Spider is a high-resolution 3D scanner based on blue light technology. It is perfect for capturing small objects or intricate details of large industrial objects in high resolution, with steadfast accuracy and brilliant color.
The scanner’s ability to render complex geometry, sharp edges and thin ribs sets our technology apart. It is an ideal industrial 3D scanner for high resolution capturing of objects such as molding parts, PCBs, keys, coins or even a human ear, followed by the export of the final 3D model to CAD software.
In this powerful 3D scanner, the technology has been honed to perfection to ensure the best possible quality of scans and a truly robust device.
Specifications Artec Space Spider Handheld 3D Scanner :
3D resolution : up to 0.1 mm
3D point accuracy : up to 0.05 mm
3D accuracy over distance : up to 0.03% over 100 cm
Colours : 24 bpp
Texture resolution : 1.3 mp
Light source : blue LED
Working distance : 0.2 – 0.3 m
Linear field of view, HxW @ closest range : 90 × 70 mm
Linear field of view, HxW @ furthest range : 180 × 140 mm
Angular field of view, HхW : 30 × 21°
Video frame rate : up to 7.5 fps
Exposure time : 0.0005 sec.
Data acquisition speed, up to 1 mln points / sec.
Multi-core processing
Output Formats
3D formats : OBJ, PLY, WRL, STL, AOP, ASCII, Disney PTEX, E57, XYZRGB
Formats for measurements : CSV, DXF, XML
Common Specifications
Weight : 0.85 kg (1.9 lb)
Dimensions, HxDxW : 190 × 140 × 130 mm
Power consumption : 12V, 24W
Interface : 1 × USB 2.0, USB 3.0 compatible
Processing capacity : 40 mln triangles / 1 GB RAM
Package includes:
– Artec Space Spider unit
– Original Power
– Battery
– Charger
– USB cords
– All connecting Cables and Manual
– Artec Studio 14 Professional License Lifetime Subscription
– 1 Year Artec Extended Warranty, Firmware updated, Fresh calibration certificate
– Pelican Hard Case
